Shaving Horses and Portable Woodworking

For bow makers and other wood crafters…A shaving horse is an invaluable tool if you create or work with odd-shaped objects that are otherwise difficult to clamp or need to constantly move around.

This simple horse was created in a morning from a large oak branch blown down in a storm and a couple spars from recent clearing.

I don’t know how I would get half my projects done without one.  A horse, in combination with a small bench or two of the same height can act as a complete workshop that is reasonably portable and adaptable.  Carpenters, furniture makers, coopers, shoemakers, jewelers, and carvers all have their specific designs and no one type will be the best at everything.  Some need to be very adjustable, while others have a very fixed purpose.  With a little patience, planning, and luck a great horse can be built for cheap or free with just a very few tools.

coopers-horse-1

A Cooper’s Horse.

I’ve collected few images of shaving horse (a.k.a. work horses) images and show some I created over the years.  If you are looking for inspiration or information on designing one for yourself, these should give an adequate starting point.  I wish I had photos of my very first horse but unfortunately, it existed at a time when I seem to have taken very few photos of my own projects and the internet wasn’t much of a place for sharing this sort of thing.

bench

Click the image to learn what this peasant is making.

In the old days of pre-internet (some of you may recall this with me) there was very little information floating around about these simple but nifty devices.  People like Roy Underhill (The Woodwright’s Shop) and Drew Langsner (Country Woodcraft) had them.  I recall seeing them rotting in yards in the Ozarks or slowly decaying in the back of family barns as a kid. While researching them later, the one consistency I discovered was the complete lack of consistency on their size, shape, height, length, or actual use.  Obviously, every bodger, tinker, and shingle maker had his own ideas and was probably limited by material availability. This ancient tool is as unique as each builder.

goodman-1966-roman-horse-rheims

“Goodman identifies the (above) relief as a cobbler making a wooden last sitting astride a small bench (‘horse’). The workpiece is held firmly on a sort of anvil by means of a strap passing down through the bench top, and held taut with his left foot. (Photo: Goodman 1964, p. 184, Museo di Civilta Romana, E.U.R., Rome. Reproduced without permission citing fair use).”

While my first horse was designed primarily around dimensional lumber found in my shop an it’s ability to fit cross-ways in a truck bed (F-150) with ease, it was perfectly functional for what I needed; primarily for shaping bows but also for carving things like spear throwers and tool handles.  Experience and use taught me the good and bad points about this model and the result has been these  better and later designs…

0106This was a good horse designed for the bowyer. Hickory arm and head, poplar cross-stretchers and a long, adjustable-tilt table to accommodate a wide variety of bow stave thicknesses.

0699Another of similar design. The base is the same but is has a square head and wider treadle to use easily with either or both feet.

0658A horse in use.  This is how they are best seen.  I actually stopped tillering for a moment to take an “action” photo in the old shop.

0321Here is another action shot fixing the tiller on someone’s bow at Winter Count several years ago. I wouldn’t normally have a giant, heavy stave leaning on the horse but the photographer insisted on it for some reason. I was just hoping it wouldn’t bean me with a very sharp draw-knife in my hand (hence my switch to the rasp for the photo).

0053

This is not my herd but that of a fellow bowyer.

Here are a few others I encountered at a bow making class in the Midwest several years ago. I liked the simplicity of these made for teaching new bowyers at the Bois d’Arc Rendezvous hosted by FirstEarth. You could make one of these with nothing but a few well-chosen scraps and a few bolts.

And my personal favorite…

Design was kept as short as possible for transport. The cross bolt where the arm hinges is a salvaged bolt from an old truck spare tire holder.

This design was kept as short as possible for transport while still being practical. The cross bolt where the arm hinges is a salvaged from an old truck spare tire holder.

Higher, more ergonomic table.

A higher, more ergonomic table and a large treadle area make this one more practical for me.

Finally, the horse above has been my more-or-less permanent workstation for the last few years and has traveled many miles around the western U.S.  Used in conjunction with a small saw bench (built Winter 2015), I have a very complete work setup that packs into the bed of the tiny Toyota pick-up.

dsc_0008-3

Click the image for more information about this project.

With all the gentrification of woodworking that has grown out of some fine blogs and books of the past few years I think it’s important to remember the roots.

Bench hook and tools. The holdfasts store in the legs so that they are always handy.

Not everyone needs to own every tool, jig, or gizmo… nor should we want to.

Few amateurs can have an enormous, dedicated work space surrounding a one-ton French-style Roubo split-top workbench, nor will he need one.  Once you figure out what you want to create, then the tools can follow as needed.  Sometimes, the big projects can be goals for the future.

The sawbench in operation with a few years, many projects, and a lot of miles on it.

If you are in need of a sturdy place to work, a portable setup that includes a saw bench and a shave horse will really improve your life.

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Robyn Hode, my boyhood hero

Robin Hood – the hero of my youth.

Robyn Hode –

An hundred shefe of arowes gode,
The hedys burneshed full bryght;

And every arowe an elle longe,
With pecok wel idyght,
Inocked all with whyte silver [or silk];
It was a semely syght.

A Gest of Robyn Hode, lines 523-8

in

English Popular Ballads, 1922 edition

England, ca. 1450 A.D.

DSC_0075_2

Classic Liquid Fuel Stoves

A look at the origins and evolution of our favorite camp stove…

This post was going to be a few words about the Primus stoves we all love and some images I’ve collected from around the web.  As usual, I found myself rambling all over the topic without a clear direction but here is a bit of an overview of liquid fuel stoves and how they have evolved over the past 150 years.  Clicking the image will link to a larger version in most cases.
1392681847-primus_usa_1899

Primus advertisement 1899. Image found on the Classic Camp Stove Forum.

Outdoor cooking has become something of a lost art for those of us raised in the industrial world, but not too long ago, what we think of as camp cooking was just plain cooking.   Several major advances made in the 19th and early 20th centuries resonate in our lives without a second thought from most of us.  Most of our grandparents or great-grandparents cooked with solid fuel (mostly wood, peat, manure, or charcoal) and their grandparents may have felt fortunate to even be able to cook indoors in bad weather. Much of the world still cooks this way and it is an eye-opener for those raised in the more industrialized countries if and when they travel abroad.

In the 19th century, the Caravan Craze, global expansionism, and long-distance campaign warfare sent massive numbers of otherwise “civilized” people back to the outdoors; often with high expectations about the board-of-fare.  Although we, as a species, have cooked over campfires for many thousands of years, this is not always convenient or desirable; whether for speed, lack of fuel, or need for a low profile in the hedgerows.  An early response to this need was the brazier or hibachi-type grill reinvented on numerous occasions in various parts of the world.  These  stoves can use small wood or charcoal but are heavy, smoky, and need large volumes of solid fuel for sustained use.  Not a good option for the traveller (sic).  When coal oil and kerosene became common, liquid fuel appeared to be the answer.

Supper

Tea at the Caravan with the Classic Svea Stove.

Although common now, liquid fuel stoves have not always been a good or safe choice for cooking on the road or in camp.  Early portable stoves used a wick and some variety of coal oil for the fuel.  The flame created with a wick is relatively low-temperature, causing incomplete combustion.

In fact, the early instructions for safe stove use are nearly the same as that of fireworks.

“LAY ON GROUND. LIGHT FUSE. GET AWAY! – USE OUTDOORS ONLY – UNDER ADULT SUPERVISION.”

Another feature of the earliest wick stoves, due to their relatively low burning temperature, is that they exude fumes and soot, like a low-quality oil lamp. This sooting and smoke make them unpleasant at best, especially in confined spaces.  Though not a terrible option for the 1850s, they are nothing as good as what would come in the next generation.

Soyer

Soyer stove.

The advancements of Alexis Soyer – The contraption above is one of the many inventions given to us by Alexis Soyer, celebrity chef and cooking guru of mid-19th century Britain.  Many of his cookbooks are still referenced and can be found for free on the web.  He was, by the way, born a Frenchman but we can forgive him this oversight for his many wonderful contributions to the world of food.

Not only did Mssr. Soyer invent several useful contraptions for cooking, but he is credited with organizing the first Soup Kitchen to help the starving Irish during the Famine.

As a further claim to fame, the large unit stove he developed for the British army during the Crimean War was such and excellent design it was still regular issue 120 years later.  But I digress from our theme.

Soyer_StoveSeen in use above, this little stove was revolutionary for the time but still left much to be desired, especially if one wanted to cook with it indoors.  I don’t believe you’d catch a sane cook using something of this sort on an actual tablecloth unless it was made from asbestos but it seemed like a good idea for the advertisement.  In the 19th century, both camp and home cookery were beginning to change drastically; up to this time the two were not very different.  Along with improvements in stoves, better cooking pots, and roasting pans, other kitchen gadgets were being developed to help make cooking better and easier.  A humble and often overlooked kitchen appliance was invented in this period…

The wind-up cooking timer –

soyer-cooking-alarm

Soyer’s Alarum.

Victorian-Alarm-Clock-Description

This little beauty is something that all modern cooks take for granted.  It seems obvious now, but Soyer realized that mothers, chefs, and camp cooks have many things to attend to at once.  He wisely decided that a dinging countdown timer timer could take some of the strain away from cooking and make for better prepared meals.

The coming of the pressurized stove – The Crimean war, the Raj in India, and other colonial ventures undertaken during Queen Victoria’s reign spurred on great advances in campaign living and long-term camping.  The East India Company and the regular military encouraged officers to bring the comforts of home as whole careers were spent thousands of miles from home creating and running an empire.  From this period, the Brits gave us great folding furniture, camp bedding, portable furnishings, and the Gypsy caravan but it took a Swede to take us to the next level, and camp technology has never looked back.

The pressurized kerosene stove –

Primus1914

Image 1914.

From the Wikipedia Entry as of October 2014:

The Primus stove, the first pressurized-burner kerosene (paraffin) stove, was developed in 1892 by Frans Wilhelm Lindqvist, a factory mechanic in Stockholm, Sweden. The stove was based on the design of the hand-held blowtorch;

From this...

The origins of the camp stove!

Lindqvist’s patent covered the burner, which was turned upward on the stove instead of outward as on the blowtorch.

Svea_fotogenkök

Improvements and variations came quickly after their introduction.

…The Primus No. 1 stove, made of brass, consists of a fuel tank at the base, above which is a “rising tube” and the burner assembly. A steel top ring on which to set a pot is held above the burner by three support legs. Other Primus-style stoves may be larger or smaller, but have the same basic design. The No. 1 stove weighs about 2½ pounds, and measures about 8½ inches high with an overall diameter of just under 7 inches. The tank, about 3½ inches high, holds a little over two pints of kerosene and will burn for about four hours on a full tank.

primuslowres

We think of this type stove as a camp stove but they were marketed far and wide for household use as well.

…Prior to the introduction of the Primus, kerosene stoves were constructed in the same manner as oil lamps, which use a wick to draw fuel from the tank to the burner and which produce a great deal of soot due to incomplete combustion.

The Primus stove’s design, which uses pressure and heat to vapourize the kerosene before ignition, results in a hotter, more efficient stove that does not soot.  Because it did not use a wick and did not produce soot, the Primus stove was advertised as the first “sootless” and “wickless” stove.

sverige270These stoves are still celebrated worldwide and are in use on every corner of the planet.  They are a labor-saving device that frees their owners from fuel collection and actually lower airborne pollutants in the immediate area.  They are also credited with limiting the natural deforestation that accompanies humans living in concentrated communities.

The ads give a hint as to how far and wide the Primus stove reached around the globe.

This Radius ad is interesting as it shows the kinship or reapplication of technology from blow torch to stove with only a little modification by the engineers.  Below, this advertisement for an aftermarket pressure cap shows the need for improvement as stoves could easily become clogged and explode as a pressurized bomb.  I narrowly escaped this hazard myself when my stove nozzle became clogged on an outing.  A chemical fire-extinguisher is never a bad Idea to have handy living on the road.

The designers continually improved this simple device with, among other features, a safety cap that intentionally failed at a lower pressure than that which would have caused the stove to turn into a brass grenade.  Although safety features were invented to reduce the number of serious accidents, I suspect these little contraptions are responsible for a fair number of burns and the loss of more than a few homes, autos, and RVs.

As with any successful product, there were and are many imitators of this relatively simple design and many still on the market models come from former Soviet Union, China, and India.

Judging by the marketing, they bring nothing but bliss and happiness to the laboring mother… but seriously, these devices were probably a huge boon to the housewife no longer in need of wood or dung for cooking fuel.

The switch to gasoline –

Although introduced in the early 20th Century, the Second World War and subsequent decade saw widespread popularity of the gasoline stove for military use.  Unlike kerosene, gasoline (or purified “white gas”) is truly explosive, not just flammable.  Placed under high pressure, these are potentially bombs.  However, gasoline or derivatives can now be found almost anywhere on earth with the spread of the internal combustion engine, making this a fuel of choice for international travelers.  As per usual with us humans, we chose practicality and convenience over safety.

The iconic early stove of this design is the Svea 123 as it it is a beautiful combination of design features including simplicity of construction, easy field repair, and heating power.

Svea_123_Optimus_99_cousin.

Classic Svea 123 and a close cousin.

Here’s a link to lighting the Svea 123 (and a little info about why they are so cool):  “DEMYSTIFYING THE SVEA 123

n.b. The original link was dead when I last checked but I have saved an archive copy here with credit to the author.

Variations on the theme are endless, from the Svea 123 (gasoline) to the Ultra-Primus double burner home range (kerosene).  The various designs proved themselves in kitchens, on river trips, mountain tops, and in virtually every modern backpacker’s gear in one form or another.  For much of the world, this style stove is still the centerpiece of kitchen cooking.

A different spin on the basic Svea design. The main feature of the 71 is it's convenient packaging.

A different spin on the basic Svea design. The main feature of the 71 is it’s convenient packaging for the traveller.

PrimusAd

Summitting  Everest, a pretty great endorsement.

As a side note to history, the design was so successful that many other companies copied the essential design.  Here are just a few ads for the Optimus line of stoves and lamps, another spin-off, from their own website showing a wide range of related products over the last century.

The modern era of the camp stove –

In my lifetime, liquid fuel backpacking stoves have undergone some serious refinements but overall, the system for liquid fuel stoves is essentially the same.  Safety has been a big issue, of course, but size (decrease) and fuel capacity (increase) are probably the biggest changes.  Many stoves use canister fuel (butane or propane), alcohol, or solid fuel pellets; but I won’t get into those as they are beyond our scope and interest here.

MSR_Patent_Model_9-XGK_Stove

A new era; the MSR XGK multi-fuel stove.

The final round of changes came from Mountain Safety Research and its later competitors.  The big innovation was to separate the fuel tank from the burner assembly and add a pressurizing system to the tank.  Small but efficient details were added like the self-lighting sparker, self-cleaning tube, and the inclusion of a lightweight wind screen.  I have used one of these for used with pretty good success but I still find myself choosing the Svea 123 for many journeys.

Links and Further Information –

This post is woefully inadequate in so many ways but it is meant as a quick overview of the pressurized liquid fuel stove we all love so much.  Here are some links to some great information on the web.

And my all time favorite, the Svea 123. We have been friends for many years.

The Base Camp is a specialist equipment internet retailer based in Littlehampton, Southern England since 1986.  They stock classic stoves and have an excellent selection of obsolete parts.

A H Packstoves Supplies and Parts – is an online seller with a wide variety.  He always has good stuff and some hard to find parts.

header_background_gradient

The Fettle Box is a good source for pieces and parts for your classic stove. I have had good luck with them.

Finally, the Classic Camp Stoves Forum.  Several images above were found here.  Information about virtually every kind of stove available.  History, art, repairs, tutorials, and reprints are all available on the Forum.

Click here for the mother load of information about Classic Stoves.

More stove ramblings to come…

Thumb Stick

A little show and tell this rainy winter morning.

Mule deer fork with rings of walnut and hickory.

I’ve been carrying this walking stick in one form or another since 2001. What does that mean? I just can’t leave well enough alone, that’s what.  It was a straight knobbed staff before attaching the stag horn but I decided it would be more useful and aesthetically pleasing with the fork on top.

A quick polish with walnut oil this morning.

The fork is not only good for resting the thumb but works well for creating shelter and provides a bit of heft should it be needed for persuasion.

The cancelous tissue is fairly light in this one as the buck had an unfortunate highway encounter with a truck. That’s how I found it.

This stick has long been a comfort on walks where stray dogs, javalinas, or other beasties may be encountered. I remember that it took me weeks of wandering around the high country, looking to find the right diameter, length, and character in a sturdy oak, in this case Quercus gambelii or Gambel oak). I don’t kill trees lightly, especially in marginal environments, as they are slow to grow and benefit the earth so much.

It’s always difficult to photograph walking sticks and longbows.

The foot of this one is capped in heavy copper to prolong life of the wood. It’s good to save those bits of hardware for re-purposing.

Terrible “selfie” of the previous hickory staff that this antler was mounted on. I can’t leave well enough alone so I changed it.

And just for fun, here is a nifty Sketchbook drawing of some uses for the traditional Scout Staff from and artist who goes by “Ishkotekay.”

Click for full size image.

Boy Scout Gear from 1925

This is a pretty good setup for any outdoorsman (our outdoors woman for that matter). By 1925, the scouts had worked out a pretty good uniform and gear setup based on many old experts not the least of which was the US Army.

If there’s a bit of a paramilitary look to the scouts it certainly owes much to its military background in Britain and further as a result of the Great War. Still, there’s a lot of good info to take away from this. These are truly the essentials.


The new internet Bushcraft world has very little on the old-timers knowledge.

Winter Count is Coming

I’m happy to say that I will be heading to the annual primitive skills gathering known as Winter Count down in the Sonoran Desert. Thankfully, it has moved to a more remote location further into the desert and far away from the Phoenix sprawl.


I will be teaching a course that I have been doing for some time now; Constructing the Ancient Frame Saw. I say “ancient” because this style saw goes back to the very beginning of metal working. It is a way to create an extreme amount of tension, and thereby stiffness, on a very small piece of metal; saving on a very precious resource.

Even though this, in essence, can be thought of as a one-off craft project. I hope that people will take time to learn the skills and take away more knowledge than a simple material good.


I think it might be easy, at first glance, to think of a project like this as a cheap way to get something that you might not be able to afford otherwise; and that is fine. However, learning basic skills like layout, simple joinery, and the use of hand tools are transferable skills that can be used for a myriad of other projects; from constructing a spear-thrower to timber frame building.

There is even plenty of opportunity to add one’s own style and artistic flare to the project.

Learning to operate even a few simple hand tools, edges and wedges in this case, connect your brain to your body in a way that pushing buttons and looking at screens could never do.

Working directly with a raw material like wood, with its own unique properties, connects us to a deeper understanding of the wider world.

Maybe I’ll see you there someday.

The Joys of a Morning Quickie

Sometimes you have needs

And also the solution.


I needed a net bag for my water bottle while I’m on the road. I knew this was going to be a problem when I left home so I threw in a ball of string in case I had some time on my hands. I almost always bring something to keep myself busy. Idle hands are the something’s something, or whatever.

The bottle in need and the raw material to make it happen.

I’ve been making nets and net bags for a very long time. Decades in fact. Some are fancy but most are quite plain and utilitarian. This one definitely falls into the latter category. However, it will serve the purpose and I suspect will be around for quite some time.


I took a few photos along the way and thought I would make a short tutorial as even simple knot work is often mysterious to the uninitiated. I hope this helps someone. It’s a great introductory project.

INSTRUCTIONS

This little bag uses a simple overhand knot technique and is probably the simplest mesh you can make. Other than a cutting instrument there really are no required tools for this so gather your string, fetch the object that will be held (in this case a water bottle), grab your knife and we can begin.

String is measured and cut.


For a regular cylinder that’s about 3:1 height to width you need to have at least twice its height in netting material. Each string will doubled so that they meet at the bottom without a complex knot.

Centers of the first strings are joined in a square knot.


The next thing to figure out is how many strings you will need. Much of this will have to do with how small you want the holes in your net; more holes, more strings. I estimate this bottle is about 12 inches in circumference and I thought the minimum number of strings I could get away with would be about 16. Since they’re doubled in the middle that means there will be 8 strings cut at least four times the length of the bottle.

The second pair of strings is added across the first.


And pulled tight.


After the first two sets of strings are put together the remainder are added like spokes on a wheel. If you’re going to use a lot of strings, say to make a cast net in this way, you would need to add a ring of cordage as the center to attach all the spokes to. Otherwise, you would end up with a bulky knot in the middle.


After all the spokes are added it becomes a simple project of making overhand knots in pairs.

The first set of knots made.


Here’s where it seems to get tricky for some people. The next step is to connect neighboring strings to create a diamond pattern. That is to say, each half of a knotted pair will join its neighbor.

It’s helpful to tie it to something when you’re working.


Connecting the alternate pairs.


Repeat ad nauseam.


If you notice your bag is coming out too skinny you need to space the knots further apart. If you need to taper it in at the base or the top, make the knots closer together.

The body of the net is finished.


Instead of binding the top in any fancy way I simply ended the last round of knots folded back to the previous. See the picture above.

I added reinforcement.


All I had was the string to work with so I had to make a heavier cord from this for a drawstring and strap. The simplest solution was to just braid up a heavier cord. In this case I just did a simple three strand braid. If I were making something more lasting I would probably finger weave a strap or maybe use a thicker, more complex braid.

Three 10 ft lengths of string become an 8-foot cord.

I ran the strap underneath the canteen to help support the weight.


The finished product closed.


And open.


Ready for the trail again.


I realize these instructions are not very detailed but this level of Technology is extremely simple and has been reinvented time and time again. It needs a little detailing if you are willing to spend the time and experiment a bit. Don’t be afraid to tie and untie things, to add more string, to have a less than perfect outcome.

This is how we truly learn. When we have to make decisions on our own based on the skills, materials, and information we have at hand.

GOOD LUCK!

Wisdom of Dan Beard

On Loneliness

“When you feel you are sleeping on the breast of your mother, the earth, while your father, the sky, with his millions of eyes is watching over you, and that you are surrounded by your brother, the plants, the wilderness is no longer lonesome even to the solitary traveler.”

~Dan Beard

Ferro Rods are in the Shop

These are securely set in mule deer antler and are fitted with a loop for suspension.

I bought a small batch of unhafted Ferrocerrum rods recently.  This came after finding out what a hit they were with some of my recent demonstrations.  Being able to produce a ridiculously hot spark with little effort in all weather amazes even the most distracted student.  Since the explosion of survival shows on television and internet media it seems these have not only become popular again but are getting bigger and bigger and bigger all the time.

Size isn’t everything folks!

And I’m not just saying that for the obvious reasons… For the minimalist hiker, camper, or general outdoorsperson, carrying a striker that will make tens of thousands of fires is generally enough.  Seriously, how long do think you’re going to live anyway?

If you are not yet familiar with this technology it is essentially a metal striker made from iron and cerium, that when crumbled, shaved, or otherwise shredded to expose the inner materials, produces a spark about 3,000°C (5,430°F) and can directly light most small tinder.  They have been around about 100 years but have really come back with the rise of the bushcraft and survival  popularity.

This batch will probably sell fast but more will be on the way soon.

I like to keep one that easily fits into a pocket or can be tied to a backpack or worn around the neck. these meet all those requirements and more so, if you are interested in one for yourself or need the perfect stocking stuffer this yuletide season, take a trip to our Etsy shop and have a look https://www.etsy.com/shop/lostworldcrafts/.

Another Bucksaw on the Loose

I am stunned to hear from several recent misguided enthusiasts to the gentle art of wilderness skills that their new hobby costs them so much money… I guess even our low-tech approach to life can be marketed and sold to the right customer with our ingrained need for newer, quicker, and “approved” gear. Let’s hope this ailment isn’t catching.

Making something for one’s self is, in itself, an act of rebellion in these troubled times so I thought I would share what I’ve been up to in the idle hours these past few days.

After someone sweet-talked me out of my last (and personal) bucksaw I was in need of a replacement. I lucked upon some beautiful walnut last year and set some aside to make a few saws. Straight-grained, strong, and beautiful, this 5/4 sawn chunk was ripe for carving into something nice. I spent far too much time in finish and detail on this one but a beautiful tool is much nicer to use than an ugly one and curves appeal more than straight lines to this gentleman.

There isn’t much need for a lengthy instructable for this design but notice that the straight grain was respected in all dimensions and runs the length of each arm. As for hardware, it was my intention to inset square nuts into the handles and connect the blade with round-head machine screws. However, looking through my hardware on hand, that would have required a trip to a store, so for now, we use carriage bolts and wing nuts.

The devil is truly in the details and it is a joy to carve such fine wood with sharp tools. The entirety is polished with Lundmark carnauba wax as it brings out the color and grain while providing excellent protection against water.
